Portable Touchscreen

Overview

Screen

21.5 inch

10 point
multi-touch

16.7M Colors

Mali-G72

1920 x 1080 FHD

60Hz

High-Quality Streaming:
The FHD resolution, vivid color range, and 60Hz refresh rate make it perfect for watching movies, TV shows, or streaming platforms like Netflix, YouTube, or Disney+. (Services are not included in the product, they need to be purchased on their platforms independently)
Dance or Yoga Companion:
Set it up for dance workouts or yoga poses, with the 60Hz refresh rate ensuring smooth transitions in videos.

Wireless

2.4+5G WiFi

Bluetooth 4.2

6Ah Large Battery

2H Battery Life

Scrollable Wheels

Easy to Go

Bluetooth Sound Integration:
Pair it with Bluetooth speakers or headphones for immersive sound quality while watching movies, playing games, or listening to music.
Short-Term Outdoor Use:
The 2-hour battery life is ideal for tasks like following a workout video in the garden, streaming a game on the patio, or setting up a temporary outdoor movie night.

Performant

MediaTek MT8788

8-Core

CPU

4GB
RAM

64GB
Internal Storage

15°/10°Tilt
Up and Down

90°/90°
Rotate
Left and Right

Android 12

Portable Entertainment Center:
Use it for streaming movies, playing music, or video gaming while moving it easily from room to room. Ideal for family movie nights or personal relaxation.
Smart Home Hub:
Integrate it with smart home devices to control lighting, thermostats, and security cameras. Its mobility allows for convenient access anywhere in the house.

Always with Me

Media Streaming

Chatting

Fitness

Cooking

Gaming

Studying

Digital Cookbook on Wheels:
Place it in the kitchen for displaying recipes, cooking tutorials, or timer apps, and roll it aside to keep the counter clear.
Fitness Companion:
Use it as a fitness guide with workout videos or virtual trainers. Its mobility lets you move it to any workout area in your home.

Hardware Specification

Table 426 Key Features

Product	Portable Multifunctional Entertainment Touchscreen
CPU	MTK8788 Octa(8)-core Cortex-A73 + Cortex-A53
Storage	64GB uFS2.1
RAM	4 GB LPDDR4x
Operating Syetem	Android 12
WiFi	Wi-Fi 802.11ac/b/g/n, 2.4GHz/5.8GHz
Bluetooth	Bluetooth 4.2
Display	1920 x 1080 60Hz, 16.7 million colors
Touch Screen	10 Point Capacitive Touch Screen
Dimensions(screen)	525.9 * 293.8 * 15 mm
Weight	15.7kg
Height	horizontal: 1140.5 mm, vertical: 1252.5 mm
Base Size	d400 x 40 mm
Tilt	U15° / W10°
Rotate	L90° / R90°
Battery Life	2H (6Ah battery)
Battery Capacity	6Ah
Full Charge Time	3H (6Ah battery)
Additional Feature	Gyroscope and gravity sensor, Google apps, wired screen mirroring input
GPU	ARM Mali-G72 MP3 700MHz
Buttons	Power, Volume +, Volume -
Bezel	23.7 / 23.7 / 16.8 / 16.8 mm
HDMI	1 x HDMI input
USB	1 x USB-C, 1 x USB-A(2.0)
Audio	TRS audio jack; 4 ohms, 5W x 2 internal speakers
Accessories	Charger x 1, Screwdriver x 1, Screws x 1 set, User Manual x 1
Mic / Camera	(Optional) 5MP HD wide-angle camera, Dual digital microphones
Gross Weight	20kg
Mounting	Stand-mounted, portable

HDMI Input

The product has an HDMI input port, you can play video in another device and let this product to display it on the large screen.

Charging

The product can be charged through a 12V DC charger, please use the charger shipped with the product to charge this product.

Buttons

The buttons on the product are: power on/off, volume, volume-.

Dimension

The dimension of the screen is 525.9 * 293.8 * 15 mm, with the base stand, the height is horizontal: 1140.5 mm, vertical: 1252.5 mm.
