PPC-J1900-101-C

The PPC-J1900-101-C is a high-quality 10.1” industrial panel PC built to meet the demands of modern industrial environments. Designed with durability and reliability in mind, it features a rugged magnesium-aluminum alloy housing with passive cooling, ensuring silent operation and minimal maintenance.

Powered by the Intel® Celeron® J1900 quad-core processor, this panel PC delivers robust computing power while maintaining a compact, energy-efficient footprint. The multi-point capacitive touchscreen with a resolution of 1280 x 800 offers a responsive and intuitive user interface, ideal for a wide range of applications including HMI, industrial automation, CNC control, and environmental monitoring.

Whether installed on a factory floor, embedded in a kiosk, or integrated into a control panel, the PPC-J1900-101-C is engineered for reliability, performance, and ease of use in demanding industrial environments.

Hardware description

PPC-J1900-101-C features multiple expansion connectors on the backside including:

  • 2 x USB 2.0 connectors;
  • 2 x USB 3.0 connector;
  • 1 x LAN connector and
  • 6 x COM connectors (5 x RS232 and 1 x RS485 connectors by default).

HDMI and GPIO connectors are not supported.
The default RAM is 4GB, expandable up to 8GB using DDR3L 1333 SO-DIMM.

WiFi/BT and 4G/LTE modules are optional and can be added during the ordering process. The device has one mini PCIe slot which can be used for either a WiFi or  a 4G module. If both are required, a 4G module will be installed in the mini PCIe slot and a WiFi module will be provided via USB.

Weight 3100 g
Dimensions 253.20 × 171.83 × 35 mm
Net weight

1200 g

Form-factor

Panel

CPU

INTEL: Celeron J1900

GPU

Intel HD Integrated Graphics, 512MB shared memory

RAM

4GB DDR3

Storage

Default mSATA 128GB SSD, supports 256/512GB

Display size

10.1"

Display resolution

1280*800

Brightness

350 NIT

Touch Screen

Capacitive

WiFi/BT

Optional

4G

Optional, the module can be purchased from other manufacturers or retailers

Ethernet

1x RJ45, 1 Gbps

mini-PCIe

1 x mini PCIe

USB

2x USB 3.0 HOST, 2 x USB 2.0 HOST ports (Type A)

RS485

1 x RS485

RS232

5 x RS232

HDMI

Not supported

GPIO

Not supported

VGA

1 x VGA out

Power Input

12V DC

Power Consumption

17W

Working Temperature

-15°C to 60°C, (No condensation)

Storage Temperature

-20 °C to 70°C, (No condensation)

Operating System

Ubuntu, Windows 7, Windows 8, Windows 10

Mounting Method

VESA, PANEL

Performances and reliability

The PPC-J1900-101-C Industrial Panel PC is powered by Intel® Celeron® J1900 quad-core CPU and equipped with a broad range of connectivity options, allowing it to meet highly demanding application requirements in harsh industrial or outdoor environments.

A specially designed magnesium-aluminum alloy housing with fins for increased heat dissipation serves as a passive cooler, eliminating the need for built-in fans. The fan-less design reduces noise, as well as the maintenance costs and efforts, increasing reliability at the same time.

Multiple Operating Systems Support

The unit comes with Ubuntu pre-installed, catering to users who prefer an open-source environment. However, for those requiring a Windows operating system, there is an option to select Windows 7, Windows 8 or Windows 10 at the time of purchase. Choosing Windows 7 and Windows 8 will incur an additional cost of $40 while Windows 10 adds $50 to the total price. Our dedicated team of software engineers has expertly crafted all necessary drivers to ensure seamless hardware compatibility across widely-used development tools.

Tailored OS Solutions
Our team is ready to assist with custom pre-installation services for projects with specific operating system requirements. Please contact us to discuss your unique needs, and we will work closely with you to provide a tailored solution that aligns perfectly with your project’s specifications.

Documentation and Downloads

Hardware Documentation

3D Design File

Order Now

PPC-J1900-101-C

SKU: PPC-J1900-101-C

Price: Price range: $598.00 through $648.00
